Generation E emitters:
more power or less consumption?
In the market since more than 15 years, our well known E emitters, GemE (for Ircon-Solaronics systems, 143 x 204 mm) and GerE (for competitor systems, 150 x 200 mm) has been offering a solution with higher efficiency while maintaining the excellent life time and power density of our emitter range.
This gave our customers and engineers two options to look for energy savings by reducing the amount of gas consumed for the same performance or increase the performance of existing systems at the same gas consumption. We can obtain savings of up to 15 % by replacing traditional emitters by our GemE emitters or increase drying capacity by up to 10 %.
Our Gas Infrared Emitters
Gem7+
Low intensity – Long lifetime
Max input power: Up to 7kW/193kW/m²
Dimensions: 143mm (5.6”) x 204mm (8”)
Expected lifetime: 6 years
Gem7E
Low intensity – Higher efficiency
Max input power: Up to 7kW/193kW/m²
Dimensions: 143mm (5.6”) x 204mm (8”)
Expected lifetime: 4 years
Gem9+
Medium intensity – Long lifetime
Max input power: Up to 9kW/262kW/m²
Dimensions: 143mm (5.6”) x 204mm (8”)
Expected lifetime: 8 years
Gem9E
Medium intensity – Higher efficiency
Max input power: Up to 9kW/262kW/m²
Dimensions: 143mm (5.6”) x 204mm (8”)
Expected lifetime: 6 years
Gem12+
High intensity – Longest lifetime
Max input power: Up to 12kW/367kW/m²
Dimensions: 143mm (5.6”) x 204mm (8”)
Expected lifetime: 10 years
Gem12Hi
High intensity – Maximum efficiency
Max input power: Up to 12kW/367kW/m²
Dimensions: 143mm (5.6”) x 204mm (8”)
Expected lifetime: 8 years
S8
Medium intensity – Average lifetime
Max input power: Up to 8kW/244kW/m²
Dimensions: 143mm (5.6”) x 204mm (8”)
Expected lifetime: 4 years
Download: Download our Gem 12-Hi emitter brochure
